Name: Used TC6515 Model 10 Ton 12 Ton Tower Cranes for Sale Hoisting Tower with Core Components Motor Gearbox Bearing
Brand: Tuoda plus Heavy & Light Machinery & Equipment Rental L.L.C
SKU: 1600910439675
Price: 45693.00 USD
Availability: InStock
Rating: 5 (1 reviews)

Description

Key attributes

Rated Loading Capacity

Other

Rated Lifting Moment

1600 KN.m

Max. Lifting Height

Other

Span

2.5---65 m

Core Components

PLC, Bearing, Gearbox, Motor, Pump, Other

Place of Origin

Hunan, China

Warranty

1 Year

Weight (KG)

45000 kg

Video outgoing-inspection

Provided

Machinery Test Report

Provided

Application

Building Construction

UNIQUE SELLING POINT

High operating efficiency

Product Name

Tower Crane

Core Components

PLC, Bearing, Motor

Application

Building Construction

After-sale Service

Provided

Advantage

Stable Operation

Delivery

Fast Delivery

Feature

Tower Crane

Showroom Location

None

Marketing Type

Ordinary Product

Warranty of core components

1 Year

Packaging and delivery

Selling Units

Single item

Single package size

XX cm

Product descriptions from the supplier

Product Overview

TC6515B-12E Tower Crane

The TC6515B-12E tower crane is a self-climbing multi-purpose machine with a horizontal jib, a trolleying mechanism and an upper slewing mechanism. The features of this machine are:

1. The performance parameters and technical indicators are at the leading level in China and reach the international advanced level. The maximum working radius is 65m and the maximum hoisting height is 200m. The appearance of the whole machine is of international popular style, very perfect, and deeply loved by users at home and abroad.

2. Multiple working methods and wide application range. The machine has working modes such as leg fixation, bottom frame fixation, exterior wall attachment and walking. It is suitable for various construction objects. The hoisting height of the outrigger stationary is 60m, the hoisting height of the undercarriage stationary is 57.5m, the hoisting height of the mobile stationary is 58.5m. The hoisting height of the crane anchored to the building reaches to 200m based on the outrigger stationary or the undercarriage stationary, added the tower sections(L68A1) and anchored devices.

FEATURES AT A GLANCE

Hoisting mechanism : M4

Slewing mechanism : M5

Trolleying mechanism : M4

Rated hoisting moment kNm : 1600

Maximum working radius : 60m

Minimum working radius : 2.5m

Maximum hoisting capacity : 12t

Trolleying mechanism

Speed m/min : 0～55

Power kw : 5.5

00:21

00:45

PRODUCT SPECIFICATIONS

No	Item	Data
1	Model name	TC6515
2	Trolleying mechanism	Speed m/min : 0～55
2	Trolleying mechanism		Speed m/min : 50/25 Power kw : 3.3/2.2	Power kw : 5.5
3	Slewing mechanism	Speed r/min : 0～0.6
3	Slewing mechanism	3		Power N·m : 95×2
4	Jacking mechanism	Working pressure MPa : 31.5
		4	Max. breakout force	Speed m/min : 0.45
		5	Tipping load	Power kw : 7.5
5	Total power kw	71.5 (Excluding erecting mechanism)
6	Working temperature ℃	－20～＋40

PRODUCT CONFIGURATION

Jacking (Erecting) structure

Slewing structure

Hoisting structure
