Name: Lifting Engineering Construction Tower Crane 75m Jib Length Topless Second-hand Tower Crane for Sale
Brand: Tuoda plus Heavy & Light Machinery & Equipment Rental L.L.C
SKU: 1601245539174
Price: 42857.00 USD
Availability: InStock
Rating: 5 (1 reviews)

Description

Key attributes

Rated Loading Capacity

16 ton

Rated Lifting Moment

3150 KN.m

Max. Lifting Height

Other

Span

4---75 m

Core Components

PLC, Engine, Gearbox, Motor, Pump, Other

Place of Origin

Hunan, China

Warranty

1 Year

Weight (KG)

50000 kg

Video outgoing-inspection

Provided

Machinery Test Report

Provided

Application

Building Construction

UNIQUE SELLING POINT

High operating efficiency

Product Name

Tower Crane

Core Components

PLC, Bearing, Motor

Application

Building Construction

After-sale Service

Provided

Advantage

Stable Operation

Delivery

Fast Delivery

Packaging and delivery

Selling Units

Single item

Product descriptions from the supplier

Product Overview

W7527-16D Tower Crane

The W7527-16D tower crane is a self-climbing multi-purpose machine with a horizontal jib, a trolleying mechanism and an upper slewing mechanism. The features of this machine are:

1. The performance parameters and technical indicator of the crane are at a leading level in

China and up to the international advanced level. The maximum working radius is 75m and the maximum hoisting height is 315m.

2. Multiple working methods and wide application range. This machine has working methods such as: outrigger stationary, undercarriage stationary, anchored to the building, so that it is applied in different construction projects. The hoisting height of the outrigger stationary or the undercarriage stationary is 60m. The hoisting height of the crane anchored to the building reaches to 315m based on the outrigger stationary or the undercarriage stationary, added the tower sections and anchored devices.

FEATURES AT A GLANCE

Hoisting mechanism : M4

Slewing mechanism : M5

Trolleying mechanism : M4

Rated hoisting moment kNm : 3150

Maximum working radius : 75m

Minimum working radius : 4.0m

Maximum hoisting capacity : 16t

Trolleying mechanism

Speed m/min : 0～80

Power kw : 7.5

00:06

00:45

PRODUCT SPECIFICATIONS

No	Item	Data
1	Model name	W7527-16D
2	Trolleying mechanism	Speed m/min : 0～80
2	Trolleying mechanism		Speed m/min : 50/25 Power kw : 3.3/2.2	Power kw : 7.5
3	Slewing mechanism	Speed m/min : 0 ～0.7
3	Slewing mechanism	3		Power kw : 7.5×2
4	Jacking (Erecting) mechanism	Working pressure MPa : 31.5
		4	Max. breakout force	Speed m/min : 0.56
		5	Tipping load	Power kw : 11
5	Total power kw	77.5 (Excluding erecting mechanism)
6	Working temperature ℃	－20～＋40

PRODUCT CONFIGURATION

Jacking (Erecting) structure

Slewing structure

Hoisting structure

SALES AND SERVICE NETWORK

Successful Project

Project in Chinese

University of Hong Kong

Project in Guangzhou

Panyu Square

Project in

Foshan City

Customer Photos

FAQ

1. Why choose us?

Prompt delivery, professional engineers are ready to solve any of your problems.

2. How can we guarantee quality?

Always a pre-production sample before mass production;Always final Inspection before shipment;

3. What can you buy from us?

Building Machinery, Tower Crane, Building Hoist, Crane Truck, Used Construction Machinery.

4. If we want to cooperate with you, can we visit your company and factory?
Sure, seeing is believing, Face to face can help us understand each other well.

5. Where can we buy machine-related parts?
We also have our own spare parts warehouse, customers can confirm with us which parts are needed.

6. Are you willing to go abroad to help us install it?
If you need help, we can send engineers to your country to assist with installation.
